    120T/H Bitumen Mixing Plant Batch Type Hot Mix Plant For Airport

    Ask Lasest Price
    Brand Name : ZOOMLINE
    Model Number : ZAP-S40-320
    Certification : CE, ISO, EAC, EMC
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 10 sets per month
    Delivery Time : about 30-40 days
    • Product Details
    • Company Profile

    120T/H Bitumen Mixing Plant Batch Type Hot Mix Plant For Airport

    120T/H Bitumen Mixing Plant Batch Type Hot Mix Plant For Airport


    Product Description

    Batch type asphalt mixing plant is designed by excellent structure which can make sure high quality asphalt mixture and high working performance. Batch type asphalt mixing plant comes from Europe, and adopted by China and many countries now. Main parts includes cold aggregate feeding system, drying drum, mixing tower, bitumen supply system, filler system, dust filtering system and control system.


    DRYING SYSTEM

    Energy saving

    The blade geometry of the dryer has been optimized to deliver and exceptionally efficient drying and heating process with reduced energy consumption, improves heating efficiency by 30% than conventional design; Because of High heating efficiency, drum surface temperature is relatively low, so the cooling time after operation is considerably shorted.


    Long service life

    Body and material blade adopt boiler iron, cover stainless steel on surface, and adopt plastic material for friction driving roller, increase the service life.


    Low heat lost

    HONEYWELL temperature intelligent control system helps burning smoothly and covered heat insulation material reduces heating lost.


    Low emission

    Adopt high combustion efficiency Italian ENERGY/EBICO burner, low exhaust gas emission (low CO2, low NO1 & NO2, SO2), Users can select a more cost effective fuel according to latest market prices (diesel, heavy oil, bulk oil, natural gas, liquefied gas, coal).


    Italian EBICO/EFIC oil or gas burner

    High combustion efficiency

    Automatic control, easy operating

    Long service life and low failure ratio


    ZOOMLINE Coal burner

    High performance, combustion stability

    PLC control, easy control

    Low emission and low cost


    Technical parameters of 40-320tph batch asphalt mixing plant

    ItemsZAP-S40ZAP-S60ZAP-S80ZAP-S100ZAP-S120ZAP-S160ZAP-S200ZAP-S240ZAP-S320
    Plant Capacity40t/h60t/h80t/h100t/h120t/h160t/h200t/h240t/h320t/h
    Cold Aggregate Feeding System
    Hopper capacity4 x 4.5m34 x 4.5m34 x 6.5m34 x 6.5m34 x 8m35 x 8m35 x 15m35 x 15m36 x 15m3
    Belt capacity60t/h80t/h100t/h120t/h140t/h180t/h220t/h280t/h360t/h
    Drying System
    Drying drum size

    1200x5200

    mm

    1200x5500

    mm

    1500x6600

    mm

    1500x6600

    mm

    1800x8000

    mm

    1900x9000

    mm

    2200x9000

    mm

    2600x9500

    mm

    2800x10200

    mm

    Drying capacity40-60t/h60-70t/h80-100t/h100-120t/h120-140t/h160-180t/h200-220t/h240-260t/h320-360t/h
    Burner (oil)

    70-300

    kg/h

    100-400

    kg/h

    60-600

    kg/h

    100-1000

    kg/h

    100-1000

    kg/h

    140-1400

    kg/h

    180-1800

    kg/h

    180-1800

    kg/h

    250-2500

    kg/h

    Fuel consumption (oil)6.5-7kg/t6.5-7kg/t6.5-7kg/t6.5-7kg/t6.5-7kg/t6.5-7kg/t6.5-7kg/t6.5-7kg/t6.5-7kg/t
    Mixing Tower
    Screen4 layer4 layer4 layer4 layer4 layer4/5 layer5 layer5 layer6 layer
    Aggregate weighing3x500kg3x1000kg3x1000kg3x1500kg3x1500kg3x2000kg3x3000kg3x3000kg3x5000kg
    Bitumen weighing3x100kg3x100kg3x100kg3x200kg3x200kg3x200kg3x500kg3x500kg3x500kg
    Filler weighing3x100kg3x100kg3x100kg3x200kg3x200kg3x200kg3x500kg3x500kg3x500kg
    Mixer capacity500kg800kg1000kg1300kg1500kg2000kg2500kg3000kg4000kg
    Mixing cycle45s45s45s45s45s45s45s45s45s
    Dust Collecting System
    Bag house filtering200m2300m2430m2480m2550m2650m2700m21050m21350m2
    Exhaust Fan power18.5/22kw30/37kw45kw55kw2x45kw2x55kw2x75kw2 x 90kw2 x 110kw
    Asphalt Temperature

    140-180

    140-180

    140-180

    140-18

    0 ℃

    140-180

    140-180

    140-180

    140-180

    140-180

    Finished Asphalt Silo (Optional)30 ton30 ton30 ton60 ton100 ton100 ton100/200 ton
    Total Power-150kw-180kw-270kw-300kw-390kw-500kw-570kw-640kw-800kw
