Energy Saving Batch Type Hot Mix Asphalt Plant
Product Description
As a professional R&D manufacturer of asphalt mixing plant, how
to make the asphalt mixing plant more energy-efficient and more
eco-friendly has always been the aim of ZOOMLINE Machinery.
Technical Parameters of ZAP-S series Eco-friendly Hot Mix Asphalt
Plant:
| Model | ZAP-S80 | ZAP-S120 | ZAP-S240 | ZAP-S320 |
| Capacity(Standard Condition) | 70-80t/h | 100-120t/h | 240t/h | 320t/h |
| Rated Capacity of Mixer | 1000kg/batch | 1500kg/batch | 3500kg/batch | 4500kg/batch |
| Bitumen aggregate ratio | 3%-9% |
| Mineral powder proportion | 4%-12% |
| Mixed material temperature (Common asphalt mixture) | 130-160℃ |
| Fuel Consumption(Standard conditions) | 6.5kg/h |
| Total Installed Power | 263kw | 393kw | 626kw | 813kw |
1. Dust collection: Negative pressure treatment of the mixing tower, the part of
vibrating screen, weighing, mixing and hot storage silo are all
equipped with a negative pressure device,which can control the
emission of the dust in the main tower from the root. The dust
removal system adopts a rotary back flushing dust collector,
two-stage dust removal and off-line cleaning. Efficient dust
removal system.
The design specially in over-limit material, overflow temporary
storage bin, fully enclosed overflow hopper, overflow material,
over-limit material hoarding treatment, not directly discharged and
centralized treatment when storage silo is full can be prevented
the dust's emission from the continuous flashing.
2. Blue smoke collection system. When the finished product is loaded, there will always be a large
amount of flue gas and dust floating out. With the blue smoke
collection system from the patented technology of the ZOOMLINE and
the sealing structure of the finished material receiving area , it
can prevent the smoke from emission. For the dust absorption added
in the part of unloading area,the dust from the material of
mixer-cleaning and waste material and the asphalt flue gas can be
disposed in effective purification.
Why Choose US
• Continuous 20 years experience in mechanical processing, nearly
15 years asphalt mixing plant specializing in the producing and
construction experiences. More than 300 sets asphalt plants are
located around the world.
• Supply various kinds of asphalt recycling solutions, cold
recycling, heat recycling, and recycling material crushing,
screening etc. Make the resource recycling, to solve the pollution
at the same time "turning waste into treasure."
• Perfect product series models, to meet the different construction
requirements.
• Each component of the equipment comes from well-known suppliers.
Stable quality, long working life. More importantly, the
installation size to meet international standards, easy to replace.
Our Service
Our professional after-sales services team could provide timely and
reliable service for any of our customers who need support.
1. Professional technical team, to provide users with equipment
selection, layout program design, construction programs and other
consultation services.
2. Technical guidance during equipment operation, PLC with remote
monitoring, large capacity recipe storage,special needs
customization.
3. Equipment installation, commissioning, training technical
support. Provide a full range of technical training on operation,
maintenance for users and equipment manager, to provide multiple
technical advice.
4. The equipment upgrades, relocation technical support in the
future. To provide seamless equipment technology upgrades,perfect
and efficient removal plan.
