Low Maintenance Cost Asphalt Batch Mix Plant
ZAP-S series asphalt batch mix plant are available from 40TPH to
320TPH, and is most popular for its high output and high
performance.
Technical parameters of ZAP-S series 40-320tph asphalt mixing plant
| Style | ZAP-S40 | ZAP-S60 | ZAP-S80 | ZAP-S100 | ZAP-S120 | ZAP-S160 | ZAP-S200 | ZAP-S240 | ZAP-S320 |
| Rated capacity(T/H) | 40 | 60 | 80 | 100 | 120 | 160 | 200 | 240 | 320 |
| Total power(kW) | ≈150 | ≈180 | ≈270 | ≈300 | ≈390 | ≈500 | ≈570 | ≈640 | ≈800 |
| Mixer volume(kg) | 500 | 750 | 1000 | 1300 | 1500 | 2000 | 2500 | 3000 | 4000 |
| Cold aggregtae kinds | 4 | 5 | 6 |
| Vibration screen | Uniaxial circular vibrating screen | Biaxial linear vibrating screen |
| Mixing cycle | 45S |
| Fuel consumption | ≤6.5kg/t finished product |
| Fuel type | Heavy/ Light oil |
| Control mode | Manual/ Automatic |
| Finished product temperature | 140-180°C |
| Aggregate weighting precision | ±0.5%(Dynamic) |
| Mineral weighting precision | ±0.5%(Dynamic) |
| Bitumen weighting precision | ±0.25%(Dynamic) |
| Dust control way | Primary cyclone dust collection , secondary bag dust collection |
| Exhaust emission concetration | ≤20mg/Nm3 |
| Finished product bin | Bottom placed / side placed |
| Optional |
40-320t/h asphalt batching plant characteristics:
1. Simple equipment structure, flexible layout, easy maintenance.
Modular design, easy to installation and move.
2. All conveyor belts are ring-bonded ,longer than belt buckle, no
mechanical failure (belt buckle is easy to break).
3. SKF bearings (stirring, drying and other key core) - bearing
long life, high temperature, low temperature and other extreme
weather effects. Reduced maintenance.
4. Mixer wear parts using CrMo alloy, effective life more than
100,000 batches. Adopt double-axis dual-motor drive, high
efficiency, low energy consumption. Asphalt with the second
measurement of high pressure spray, stir quickly and evenly.
5. International first-line brand of electronic control components.
PLC supporting remote detection (through the Internet can be remote
on the system fault detection, recovery).
6. Big Dust removal area, and supporting a dust humidifier, to
prevent powder warehouse flying.
7. All reducers are used hardened gear reducer ( long life, low
failure, no oil leakage compared with cycloid reducer)
8. Machining parts are own processing, quality, delivery period are
guaranteed, parts supply convenient and quickly in the future.
9. All equipment of our asphalt mixing plant has test assembly and
trial running before living the factory. To make sure each parts
working reliable, connected correctly. Ensure the quality of the
equipment which is stable and reliable.
10. Each component of the equipment comes from well-known
suppliers. Stable quality, long working life. More importantly, the
installation size to meet international standards, easy to replace.
11. Variety kinds of fuels to choose, for different regions,
different users, you can choose coal, heavy oil, diesel, gas and
other fuels, we have a wealth of construction experiences on each
fuel using, we can provide perfect solutions to customers.
